OMNIS R1

OMNIS R1

Monitoring

Megapixel VR’s OMNIS R1 provides aggregated, real-time health monitoring of large-scale video displays and distribution systems. A single unit can monitor hundreds of LED processors on-premises or in the cloud with a single health map view. Combine multiple units via cloud-based connection to access an on-demand centralized view of over one billion pixels from any location.

Specifications
Monitoring Aggregates hundreds of screen processors into a single map view
Heat map view of all tiles in a display
Network 8 x 10/100/1000 Ethernet ports (bridged) for device monitoring
Management 4 x 10/100/1000 Ethernet ports
Power 100-240VAC, 50/60Hz, 3.8A
Dims & Weight 1RU | 481.5 x 44.2 x 393 mm | 3.9kg
Operating Conditions Indoor / -15°C ~ 40°C
Web API Application Programming Interface (API) exposing full control and monitoring of OMNIS R1 via JSON-RPC over a REST-style interface. Allows for integration with other external systems.
Cloud-Based Monitoring Option Centralized and secure remote management of multiple OMNIS R1 systems across multiple locations, through a single pane-of-glass interface.
